Description
The Brocade XBR-000463 64G SWL SFP+ Optical Transceiver (8-Pack) delivers cutting-edge performance and reliability for modern data center environments. Designed to work seamlessly with Brocade 64G switches and directors, this short-wavelength (SWL) transceiver enables ultra-fast Fibre Channel and Ethernet connectivity, supporting data rates up to 57.8Gb/s.
With its dual-mode operation, the transceiver automatically adjusts between Fibre Channel (16G/32G/64G) and Ethernet (10GbE/25GbE/50GbE) protocols, ensuring maximum flexibility across evolving SAN and LAN infrastructures. Built to meet FC-PI-7 and IEEE 802.3cd standards, it ensures compatibility and robust interoperability.
Each SFP+ module in this 8-pack provides real-time diagnostic monitoring for optical power, temperature, voltage, and laser bias current via the SFF-8472 interface, offering proactive performance insight. The hot-swappable design, combined with rigorous Brocade certification, guarantees dependable operation in mission-critical, high-availability network fabrics.
Ideal for high-performance applications, the Brocade 64G SWL SFP+ transceiver ensures low-latency, high-bandwidth connections, while maintaining energy efficiency and long-term reliability.
| Category | Details |
|---|---|
| Model | Brocade XBR-000463 |
| Description | 64G Short Wavelength (SWL) SFP+ Optical Transceiver (8-Pack) |
| Form Factor | SFP+ |
| Data Rate | 57.8Gb/s, 28.05Gb/s, 14.025Gb/s (Fibre Channel) |
| Ethernet Speeds Supported | 10GbE, 25GbE, 50GbE |
| Optical Wavelength | 850 nm VCSEL (840–860 nm range) |
| Media Type | Multimode Fiber (MMF) |
| Connector Type | LC Duplex |
| Transmission Distance | Up to 100 m on OM4, OM4+, and OM5 fiber |
| Diagnostics (DOM) | Supported – real-time monitoring (Tx/Rx power, bias current, temp, voltage) |
| Power Dissipation | 1.6 W |
| Operating Temperature | 0°C to 70°C (32°F to 158°F) |
| Storage Temperature | −40°C to 85°C (−40°F to 185°F) |
| Compliance Standards | FC-PI-7, IEEE 802.3cd, SFF-8402, SFF-8472 |
| Safety Standards | IEC 60825-1 Class 1 / CDRH Class 1 laser (eye-safe) |
| Certifications | UL/CSA 62368, EN 60950, EN 60825 |
| Hot-Swappable | Yes |
| RoHS Compliance | Yes |
| Package Quantity | 8-pack |
| Part Number | XBR-000463 |
| Manufacturer | Broadcom (Brocade Division) |
