Description
The SMART Board RX286-C1 86-inch interactive display is engineered to deliver powerful collaboration experiences across modern classrooms and enterprise meeting spaces. Featuring a brilliant 4K UHD resolution and high 490 cd/m² brightness, it ensures crystal-clear visuals with wide 178° viewing angles, making content visible from anywhere in the room. The optically bonded, anti-glare, anti-fingerprint, heat-tempered glass enhances durability while maintaining exceptional clarity and touch precision.
Powered by the iQ embedded Android operating system, the RX286-C1 enables seamless access to digital whiteboarding, web browsing, screen sharing, and cloud-based tools without requiring external devices. With support for Google Play Store and over-the-air updates, users benefit from a continuously evolving, app-rich environment tailored for productivity and engagement.
HyPr Touch™ technology with Advanced IR delivers ultra-responsive interactivity with up to 50 simultaneous touch points and sub-4 ms response time, ensuring smooth and precise collaboration. Integrated audio and conferencing features, including dual 20 W speakers, a 15 W subwoofer, and an 8-microphone array with echo cancellation, provide a complete all-in-one solution for hybrid communication.
With extensive connectivity options such as HDMI 2.1, USB-C with power delivery, OPS PC compatibility, and NFC login, the RX286-C1 is designed for flexibility, performance, and ease of use in dynamic collaborative environments.
| Category | Specification |
|---|---|
| Display Size | 86-inch |
| Resolution | 4K UHD (3840 × 2160) |
| Brightness | 490 cd/m² |
| Refresh Rate | 60 Hz |
| Response Time | ≤ 8 ms |
| Viewing Angle | 178° |
| Glass Type | Optically bonded, anti-glare, anti-fingerprint, heat-tempered |
| Touch Technology | HyPr Touch™ with Advanced IR |
| Touch Points | Up to 50 simultaneous touch points |
| Touch Response Time | ≤ 4 ms |
| Accuracy | 1 mm |
| Operating System | Android 13 (upgradeable to Android 15) |
| CPU | Octa-core |
| Memory | 8 GB DDR4 |
| Storage | 64 GB (expandable up to 576 GB) |
| Audio | Dual 20 W speakers and 15 W subwoofer |
| Microphones | 8-microphone array with echo cancellation |
| Connectivity | HDMI 2.1, USB-C, USB-A, USB-B, RJ45 LAN, RS-232 |
| Wireless | Wi-Fi 6E, Bluetooth 5.2 |
| NFC | Integrated NFC reader with SMART account login support |
| OPS Support | SMART PCM OPS modules supported |
| Power Requirements | 100V–240V AC, 50–60 Hz |
| Operating Temperature | 5°C to 35°C |
| Mounting | VESA 800 × 600 mm |
| Included Accessories | Stylus pens (x2), erasers (x2), remote control, cables, NFC cards |
| Sensors | Ambient light, proximity, temperature, humidity, air quality sensors |
