Description
The SonicWall TZ470W Threat Edition is a next-generation firewall (NGFW) built for small to mid-sized businesses and distributed enterprises. Featuring Wi-Fi 5 connectivity, high port density, and advanced threat protection services, it delivers enterprise-class security in a compact desktop form factor. Powered by SonicOS 7.0, it integrates firewalling, VPN, SD-WAN, and wireless capabilities with centralized management for seamless operation. With Real-Time Deep Memory Inspection (RTDMI™) and Capture Advanced Threat Protection (ATP), the TZ470W safeguards against malware, ransomware, and zero-day threats. This Threat Edition includes a 1-year TotalSecure subscription for comprehensive gateway security and support.
| Category | Details |
|---|---|
| Brand | SonicWall |
| Model | TZ470W Threat Edition |
| SKU | 02-SSC-7269 |
| Form Factor | Desktop |
| Connectivity | Wired & Wireless (Wi-Fi 5) |
| Bundled Services | 1-Year TotalSecure |
| Operating System | SonicOS 7.0 |
| Firewall Throughput | 3.5 Gbps |
| Threat Prevention | 1.5 Gbps |
| Application Throughput | 2 Gbps |
| VPN Throughput | 1.5 Gbps |
| TLS/SSL Inspection | 600 Mbps |
| Maximum Connections | 1,000,000 SPI; 250,000 DPI |
| VPN Tunnels | 150 site-to-site; up to 200 IPSec clients |
| SSL VPN Licenses | 2 (max 150) |
| Wi-Fi Frequency Bands | 2.4 GHz, 5 GHz |
| Interfaces | 6x 1GbE RJ-45, 2x 1GbE WAN RJ-45, 2x 2.5GbE SFP+, 2x USB 3.0, 1x Console RJ-45 |
| Storage | Built-in and expandable up to 256GB |
| Security Features | Firewall, IPS, Gateway AV, Anti-Spyware, Content Filtering, Application Control, RTDMI™, Capture ATP |
| Management | Zero-Touch Deployment, SonicExpress App, Cloud-based management |
| Power | External adapter, redundant power option |
| Dimensions | 7.5 x 5.3 x 1.4 in |
| Weight | 30.68 oz |
| Compliance | FCC, UL, TUV GS, ICSA Firewall/AV, FIPS 140-2 Level 2, RoHS, WEEE |
| Warranty/Support | Includes 1-year TotalSecure subscription |
