Description
The SonicWall TZ570W Advanced Edition is a next-generation firewall (NGFW) designed for mid-sized organizations and distributed enterprises. Equipped with Wi-Fi 5 (802.11ac Wave 2) and 1-Year TotalSecure services, this high-performance appliance delivers robust network security, seamless scalability, and simplified deployment.
Built on next-gen hardware, the TZ570W offers 5 Gigabit Ethernet interfaces, expandable storage up to 256GB, and support for advanced security features such as Deep Packet Inspection (DPI), anti-malware, VPN, content filtering, and intrusion prevention.
With Zero-Touch Deployment, businesses can roll out multiple devices across locations with minimal IT involvement. Unified management with SonicWall Switches and SonicWave Access Points provides a streamlined, single-pane-of-glass administration experience.
Ideal for organizations handling encrypted traffic, connected devices, and high-speed mobility, the TZ570W ensures real-time breach detection and prevention without compromising performance.
| Category | Details |
|---|---|
| Device Type | Security Appliance |
| Bundled Services | 1-Year TotalSecure |
| Form Factor | Desktop |
| Connectivity | Wired & Wireless (Wi-Fi 5 / 802.11ac Wave 2) |
| Interfaces | 6x 1GbE RJ-45, 2x 1GbE WAN RJ-45, 2x SFP+, 2x USB 3.0, 1x RJ-45 console, 1x micro-USB console |
| Routing Protocols | OSPF, RIP-1/2, BGP, Static, PBR |
| Remote Management | SNMP v2/v3, HTTP, HTTPS, SSH, CLI |
| Firewall Throughput | 4 Gbps |
| Threat Prevention Throughput | 2 Gbps |
| VPN Throughput (IPSec) | 1.8 Gbps |
| Concurrent SPI Connections | 1,250,000 |
| DPI Connections | 400,000 |
| DPI SSL Connections | 50,000 |
| SSL VPN Licenses | 2 included (max 200) |
| Manageable Access Points | Up to 32 |
| Encryption | DES, 3DES, MD5, SHA-1, WPA/WPA2, AES (128/192/256-bit) |
| Features | Firewall, NAT, VPN, IPS, Anti-Malware, Content Filtering, WIDS/WIPS, SD-WAN, QoS, VLAN, DoS/DDoS Protection |
| OS | SonicOS 7.0 |
| MTBF | 23.3 years |
| Power Consumption | 15.3 W |
| Dimensions (W x D x H) | 8.9 x 5.9 x 1.4 in |
| Weight | 34.92 oz (Shipping: 4.37 lbs) |
| Operating Temp. | 32°F to 104°F |
| Humidity Range | 5% – 95% (non-condensing) |
