Description
The NVIDIA MMA1B00-C100D is a high-performance, 4-channel QSFP28 optical transceiver designed for 100GbE Ethernet connectivity over multimode fiber (MMF). It supports data rates up to 100Gb/s and provides transmission distances of up to 100 meters on OM4 fiber and 70 meters on OM3 fiber at 100Gb/s.
The transceiver converts four 25Gb/s electrical input channels into four optical signals operating at 850 nm, while the receiver converts four optical inputs back into electrical differential output signals. Selectable retiming for both transmit and receive paths enables compatibility with both 100GBASE-SR4 and 40GBASE-SR4 Ethernet applications.
The MMA1B00-C100D features an MPO/UPC optical interface, programmable transmit input equalization, programmable receive output amplitude and emphasis, and digital diagnostic monitoring for temperature, supply voltage, and optical power through an I2C management interface. Its hot-pluggable QSFP28 design, low typical power consumption, and RoHS compliance make it well suited for high-density enterprise, data center, and NVIDIA Ethernet networking environments.
Product Highlights
- Up to 100Gb/s data rate
- QSFP28 SR4 optical transceiver
- Supports 100GBASE-SR4 and 40GBASE-SR4
- 850 nm operating wavelength
- Up to 100 m on OM4 at 100Gb/s
- Up to 70 m on OM3 at 100Gb/s
- Up to 100 m on OM3 at 40Gb/s
- 4-channel optical architecture
- MPO/UPC optical connector
- Selectable Tx and Rx retiming
- Digital diagnostic monitoring
- Hot-pluggable design
- Typical power consumption of 2.2 W with retiming
- RoHS compliant
- Qualified for NVIDIA Ethernet end-to-end systems
Technical Specifications
| Specification | Details |
|---|---|
| Brand | NVIDIA |
| SKU / Part Number | MMA1B00-C100D |
| Product Type | Optical Transceiver |
| Form Factor | QSFP28 |
| Ethernet Standards | 100GBASE-SR4, 40GBASE-SR4 |
| Maximum Data Rate | Up to 100Gb/s |
| Number of Channels | 4 |
| Channel Data Rate | 25Gb/s per channel at 100GbE |
| Fiber Type | Multimode Fiber (MMF) |
| Operating Wavelength | 850 nm |
| Optical Connector | MPO |
| Connector Polish | UPC, Un-angled |
| Maximum Reach – OM4 at 100Gb/s | Up to 100 m |
| Maximum Reach – OM3 at 100Gb/s | Up to 70 m |
| Maximum Reach – OM3 at 40Gb/s | Up to 100 m |
| Retiming | Selectable for Tx and Rx |
| Tx Equalization | Programmable Tx Input Equalizer |
| Rx Controls | Programmable Output Amplitude and Emphasis |
| Digital Diagnostics | Temperature, Supply Voltage, Optical Power |
| Management Interface | Two-wire I2C |
| QSFP28 Compliance | SFF-8665 |
| DDM Compliance | SFF-8636 |
| Power Supply | Single 3.3V |
| Power Class | QSFP28 Power Class 3 |
| Maximum Power | 2.5 W |
| Typical Power Consumption | 2.2 W with Retiming |
| Hot Pluggable | Yes |
| Laser Safety | Class 1 |
| RoHS Compliant | Yes |
| System Qualification | NVIDIA Ethernet End-to-End Systems |
