The Eaton Tripp Lite CSC16ACW is a secure, stationary AC charging cabinet designed to safely charge, store, and organize up to 16 Chromebooks or laptops with screens up to 15 inches. Ideal for education, office, healthcare, retail, and commercial environments, this locking steel cabinet combines reliable power delivery with durable construction and smart cable management.
Sixteen NEMA 5-15R AC outlets provide up to 1,440 watts of total power, allowing device adapters to charge simultaneously while remaining neatly concealed. A built-in circuit breaker protects connected equipment from overloads, while flow-through ventilation helps prevent overheating during extended charging cycles.
The CSC16ACW ships fully assembled and supports flexible installation on walls, desks, counters, tables, or floors. Locking front doors with a 3-point locking mechanism enhance device security, and removable dividers accommodate thicker devices or power adapters. For added mobility, the cabinet can be converted into a rolling cart using an optional handle kit (sold separately).
| Specification | Details |
|---|---|
| Brand | Eaton Tripp Lite |
| Model | CSC16ACW |
| Product Type | Multi-Device AC Charging Station |
| Charging Capacity | Up to 16 devices |
| Compatible Devices | Chromebooks, laptops, tablets (via AC adapters) |
| Max Device Size | Up to 15 in. screen |
| Charging Method | AC charging |
| Outlet Type | 16 × NEMA 5-15R |
| Total Power Capacity | 1,440 W |
| Input Voltage | 120V AC |
| Input Frequency | 50 / 60 Hz |
| Input Plug | NEMA 5-15P |
| Input Cord Length | 10 ft (3.05 m) |
| Cabinet Material | Steel |
| Color | White |
| Security | Locking doors with included keys |
| Ventilation | Flow-through ventilation |
| Circuit Protection | Built-in circuit breaker |
| Mounting Options | Wall, desk, table, counter, or floor |
| Mobility Option | Optional cart conversion (sold separately) |
| Unit Dimensions (H × W × D) | 18.8 × 30.3 × 20.2 in |
| Unit Weight | 75.17 lb |
| Assembly | Ships fully assembled |
| Certifications | UL 1363, RoHS compliant |
| Warranty | 2-Year Limited Warranty |
