Description
The TYAN Thunder HX FT65T-B5652 (B5652F65TV6E2H-2T-N) is a high-performance 4U pedestal GPU server platform designed for demanding HPC, AI, and enterprise workloads. Built around a single LGA4677 socket supporting 4th Gen Intel® Xeon® Scalable Processors, this system delivers exceptional compute density and expansion flexibility.
With support for up to 8 DDR5 DIMM slots and massive memory scalability, the platform is ideal for memory-intensive applications. It features advanced PCIe Gen5 expansion, enabling multiple high-performance GPU cards for accelerated computing.
The chassis supports both NVMe and hot-swap SATA/SAS storage configurations, offering fast data access and scalable capacity. Integrated IPMI/iKVM remote management ensures reliable monitoring and control in data center or workstation deployments.
| Specification | Details |
|---|---|
| Brand | TYAN |
| Product Line | Thunder HX |
| Platform Model | FT65T-B5652 |
| SKU | B5652F65TV6E2H-2T-N |
| Form Factor | 4U Pedestal / Tower GPU Server |
| Processor Socket | Single LGA4677 |
| Supported CPU | 4th Gen Intel® Xeon® Scalable Processors |
| Max CPU TDP | Up to 350W |
| Chipset | Intel C741 |
| Memory Slots | 8 × DDR5 DIMM Slots |
| Max Memory Capacity | Up to 1TB RDIMM / 2TB 3DS RDIMM |
| Memory Speed | DDR5 4800 ECC |
| PCIe Expansion | (1) PCIe Gen5 x8 + (4) PCIe Gen5 x16 |
| Storage Bays | (2) 2.5" Hot-Swap NVMe + (6) 3.5"/2.5" Hot-Swap HDD/SSD |
| Storage Interfaces | SATA 6Gb/s + SAS 12Gb/s + NVMe Support |
| LAN Ports (-2T Model) | Dual 10GbE + 1GbE + Dedicated IPMI GbE |
| Server Management | Onboard BMC with IPMI 2.0 + iKVM |
| Power Supply | Up to 2000W Platinum/Gold PSU Options |
| Cooling | High-performance fan duct with multiple system fans |
| Use Case | AI Training, HPC, GPU Compute, Enterprise Workloads |
