Description
The TYAN Transport CX TD76-B8058 (B8058T76X4-270TE4HR) is a high-density 2U4N cloud server platform built for modern enterprise and hyperscale environments. Designed around the AMD EPYC 9004 Series (Socket SP5), this system delivers outstanding compute performance, memory scalability, and storage flexibility for demanding cloud and virtualization workloads.
Each node supports up to 16 DDR5 DIMM slots with total memory capacity reaching 2TB, ensuring exceptional throughput for data-intensive applications. The platform also features hot-swap NVMe E1.S bays for fast and efficient storage expansion, making it ideal for cloud deployment, HPC, and software-defined infrastructure.
With redundant 2,700W Titanium-rated power supplies, onboard IPMI remote management, PCIe Gen5 expansion, and compact 4-node density, the TD76-B8058 provides maximum perf
| Specification Category | Details |
|---|---|
| Brand | TYAN |
| Product Line | Transport CX |
| Model | TD76-B8058 |
| SKU | B8058T76X4-270TE4HR |
| Form Factor | 2U Rackmount, 4 Nodes (2U4N) |
| Processor Support | 1× AMD EPYC 9004 Series (Socket SP5) |
| Max CPU TDP | Up to 360W |
| Memory Slots | 16× DDR5 DIMM slots per node |
| Max Memory Capacity | Up to 2,048GB DDR5 RDIMM |
| Memory Speed Support | DDR5 4800MHz (1DPC) / 3600MHz (2DPC) |
| Storage Bays | 4× Hot-swap NVMe E1.S per node (Total 16 bays) |
| Additional Storage | 4× NVMe M.2 22110/2280 per node |
| Expansion Slots | PCIe Gen5 x16 + OCP 3.0 PCIe 5.0 mezzanine |
| Networking | 1× GbE LAN + 1× Dedicated IPMI GbE port |
| Remote Management | IPMI 2.0 with iKVM (AST2600 BMC) |
| Power Supply | 1+1 Redundant 2,700W CRPS (80+ Titanium) |
| Cooling | 4× 8cm system fans |
| Deployment Use Case | High-density cloud, virtualization, hyperscale datacenter |
ormance per rack unit for next-generation datacenters.
