Description
The Smart-AVI HDR-8X8-PLUS-S is a high-performance 4K HDMI matrix switch designed to route up to eight HDMI sources to eight displays with complete flexibility and zero signal interruption. Built for professional AV environments, this non-blocking matrix enables simultaneous distribution of Ultra HD video and multi-channel audio across multiple endpoints without the need for constant cable swapping.
Supporting resolutions up to 4K at 30Hz, this matrix ensures crisp, high-quality visuals for demanding applications such as control rooms, digital signage, video walls, and enterprise AV systems. With advanced control options including front panel switching, RS-232, and integrated TCP/IP web-based management, users can easily configure and manage signal routing locally or remotely.
Engineered for reliability and scalability, the HDR-8X8-PLUS-S also features EDID learning for seamless compatibility with connected devices, ensuring optimal performance across a wide range of HDMI sources such as computers, Blu-ray players, gaming consoles, and media servers. This solution is ideal for environments requiring dependable, centralized video distribution with professional-grade control and performance.
| Specification | Details |
|---|---|
| Video Format | HDMI 1.4 |
| Resolution Support | Up to 4K (3840 x 2160 @ 30Hz) |
| Video Bandwidth | 10.2 Gbps |
| Inputs | 8 x HDMI (supports audio and video) |
| Outputs | 8 x HDMI (supports audio and video) |
| Audio Support | Up to 7.1 channel audio |
| Switching Type | Non-blocking matrix |
| HDCP Compliance | HDCP 1.0 / 1.1 |
| DVI Compatibility | Single-link DVI-D (with adapter) |
| Maximum Cable Length | Up to 20 ft |
| Control Methods | Front panel, RS-232, TCP/IP (web browser) |
| Network Control | Integrated TCP/IP with web interface |
| EDID Management | EDID learning mode |
| Power Supply | External 100–240VAC, 12VDC |
| Power Consumption | 20W |
| Operating Temperature | 0 to 35°C (32 to 95°F) |
| Storage Temperature | -20 to 85°C |
| Humidity | Up to 95% |
| Dimensions | 17.25" W x 2.0" H x 9.0" D |
| Weight | 5.6 lbs |
| Compliance | UL, CE, RoHS |
