Description
The Shure ULXD4Q Quad-Channel Digital Wireless Receiver delivers scalable, high-performance wireless audio for large venues, enterprise A/V installations, and mission-critical environments. Designed for reliability and clarity, this 1RU rackmount receiver supports up to four channels of pristine digital audio with ultra-low latency and robust RF performance.
Operating in the X52 frequency band (902–928 MHz), the ULXD4Q provides a wide tuning range and supports up to 12 transmitters per band, making it ideal for expanding multi-channel setups. Integrated Dante networking and dual Ethernet ports enable seamless audio routing and system control across complex networked environments.
With AES-256 encryption, advanced diversity reception, and professional-grade XLR outputs, this receiver ensures secure, interference-resistant transmission with exceptional audio fidelity. Built for flexibility, it integrates easily into installed systems while maintaining the rugged reliability expected in professional deployments.
| Specification | Details |
|---|---|
| Wireless Technology | Digital UHF |
| Frequency Band | X52: 902 to 928 MHz |
| Tuning Range | 26 MHz |
| Number of Channels | 4 Digital Audio Channels |
| Max Transmitters per Band | Up to 12 |
| RF Channel Frequencies | 1040 |
| Operating Range | Up to 100 m (328 ft) |
| Latency | < 2.9 ms |
| Encryption | AES-256 Secure Encryption |
| Diversity | Yes |
| Receiver Type | Rackmount (1 RU, 19") |
| Audio Outputs | 4 x XLR Balanced Outputs |
| Network Connectivity | 2 x RJ45 (Dante, DHCP, Manual IP) |
| RF Cascade Ports | 2 x RF Cascade Ports |
| Antenna | 2 x External BNC 1/2 Wave (Rear-Mount) |
| Gain Range | -18 to +42 dB (1 dB Steps) |
| Frequency Response | 30 Hz to 20 kHz ±1 dB |
| Display | Backlit LCD |
| Power Requirements | 100 to 240 VAC, 50/60 Hz |
| Power Consumption | 0.32 A |
| Housing Material | Steel |
| Dimensions | 19 x 10.8 x 1.7 in |
| Weight | 7.6 lb (3.4 kg) |
| Included Accessories | Rackmount Kit, Antennas, BNC Cables, Ethernet Cable, Power Cord |
| Expandability | Expandable up to 12 Channels |
| Application | Large Venues, Broadcast, Corporate A/V, Installed Systems |
