Description
The Shure ULXD4Q Quad-Channel Digital Wireless Receiver delivers enterprise-grade wireless audio performance for large venues, broadcast environments, and professional AV installations. Housed in a single 1RU rackmount chassis, this system integrates four independent digital receivers, enabling high-density wireless deployment with exceptional clarity and reliability.
Operating in the H50 UHF band (534–598 MHz), the ULXD4Q provides a wide 64 MHz tuning range and supports up to 60 channels in coordinated environments. Advanced Digital Predictive Switching Diversity ensures stable RF performance by proactively preventing dropouts, while AES-256 encryption safeguards every transmission for secure applications.
Designed for scalability and networked control, the receiver features dual Ethernet ports with Dante digital audio networking, enabling seamless integration into modern AV infrastructures. Audio summing capability allows the unit to function as a 4-channel mixer, reducing the need for additional hardware.
With pristine 24-bit/48 kHz audio quality, flexible gain control, and intuitive front-panel monitoring, the ULXD4Q is engineered for mission-critical applications where performance, scalability, and reliability are non-negotiable.
| Specification | Details |
|---|---|
| Wireless Technology | Digital UHF |
| RF Frequency Band | H50: 534 to 598 MHz |
| Tuning Range | 64 MHz |
| Number of Audio Channels | 4 Independent Channels |
| Receiver Type | 1RU Rackmount (19") |
| Diversity | Digital Predictive Switching Diversity |
| Max Operating Range | Up to 328 ft (100 m) |
| Max Systems per Band | Up to 60 Channels |
| Latency | Less than 2.9 ms |
| Encryption | AES-256 Secure Encryption |
| Audio Output | 4 x XLR 3-Pin Balanced Outputs |
| Audio Frequency Response | 30 Hz to 20 kHz ±1 dB |
| Gain Range | -18 to +42 dB (1 dB Steps) |
| Network Connectivity | 2 x RJ45 Ethernet (Dante, DHCP, Manual IP) |
| RF Cascade Ports | 2 x RF Cascade Ports for antenna distribution |
| Antennas | 2 x Removable BNC External Antennas |
| Audio Summing | Built-in 4-channel mixing capability |
| Display | Backlit LCD with RF and audio metering |
| Power Requirements | 100 to 240 VAC, 50/60 Hz |
| Power Consumption | 0.32 A |
| Construction | Steel chassis |
| Weight | 7.6 lb (3.4 kg) |
| Included Accessories | Rackmount hardware, antennas, BNC cables, Ethernet cable, power cord |
| Transmitters Included | Not included |
| Microphone Included | Not included |
