Description
The APC Smart-UPS X SMX750C delivers reliable, network-grade power protection for servers, network equipment, and critical IT infrastructure. Designed in a versatile 2U rack/tower convertible form factor, this 750VA / 675W line-interactive UPS provides pure sine wave output for compatibility with sensitive electronics.
Equipped with SmartConnect remote monitoring, USB and serial connectivity, and support for extended runtime battery packs, the SMX750C is ideal for small data centers, edge deployments, and enterprise network closets. Automatic Voltage Regulation (AVR) stabilizes incoming power while preserving battery life, ensuring consistent uptime during power disturbances.
| Specification | Details |
|---|---|
| Brand | APC |
| Model | Smart-UPS X |
| SKU | SMX750C |
| UPS Type | Line-Interactive |
| Form Factor | Rack/Tower Convertible |
| Rack Height | 2U |
| Power Capacity | 750 VA / 675 W |
| Input Voltage | 120 V AC |
| Input Plug | NEMA 5-15P |
| Output Voltage | 120 V AC |
| Output Receptacles | 8 × NEMA 5-15R |
| Waveform | Pure Sine Wave |
| Output Frequency | 50/60 Hz Auto-Sensing |
| Runtime at Full Load | Up to 11.5 minutes |
| Runtime at Half Load | Up to 27 minutes |
| Battery Type | Internal Sealed Lead-Acid |
| Expandable Runtime | Yes |
| Battery Recharge Time | Approx. 3 hours |
| Connectivity | USB, Serial (RS-232), SmartConnect |
| Network Monitoring | SmartConnect Cloud Monitoring |
| Surge Energy Rating | 645 Joules |
| Noise Level | 40 dBA |
| Color | Black |
| Dimensions (H × W × D) | 17.0 × 3.5 × 19.3 in |
| Weight | 48.6 lb |
| Mounting Options | Rack-mount or Tower |
| Included Accessories | Rack rails, USB cable, Serial cable, Ethernet cable |
| Warranty | 3-Year UPS / 2-Year Battery |
