Description
Extend high-performance computing access with the Vertiv Avocent LV5520T-400 KVM Extender Transmitter. Part of the LongView 5000 Series, this unit delivers 4K @ 60Hz dual-head video over long distances via copper or fiber connection. With intelligent EDID management, secure firmware upgrades, and real-time USB emulation, it’s built for demanding IT environments requiring uninterrupted performance, crystal-clear visuals, and maximum control. The LV5520T supports a variety of platforms including PC, Mac, Linux, Unix, and Sun, and features dual DisplayPort, USB 2.0, and audio ports—making it an ideal fit for modern workstations and control rooms.
| Specification | Details |
|---|---|
| Manufacturer | Vertiv |
| Brand | Vertiv AVOCENT |
| Series | LongView 5000 |
| Model Number | LV5520T-400 |
| Product Type | KVM Extender Transmitter |
| Video Resolution | Up to 4096 x 2160 @ 60Hz (Dual-Head 4K) |
| Connectivity | Wired (Copper or Fiber) |
| Display Interface | 2 x DisplayPort |
| USB Ports | 2 x USB 2.0 |
| Audio Ports | Microphone and Headphone (3.5mm) |
| Local Console Output | Yes |
| KVM Technology | Digital, True USB Emulation |
| Max Distance | 13,123 ft (4,000 m) |
| Input Voltage | 100–240V AC |
| Power Consumption | 18W |
| Form Factor | Rack-Mountable, 1U |
| Transmitter Dimensions | 1.54" H x 7.32" W x 5.83" D |
| Weight | 2.84 lbs |
| Platform Compatibility | PC, Mac, Unix, Sun, Linux |
| TAA Compliant | Yes |
| Environmental Compliance | China RoHS |
| Package Contents | Cables, PSU, Guides, Warranty Card, Doc Wallet |
| Warranty | 2-Year Limited |
| Product Condition | New and Factory Fresh |
| Shipping Weight | 3 lbs |
