Description
The Vertiv Avocent Cybex SC945D-001 Secure Desktop KVM Switch delivers robust desktop protection for users in government, defense, and other sensitive environments. Featuring 4 secure channels, dual DisplayPort video, and Dedicated Peripheral Port (DPP) support, this NIAP PP 3.0-compliant KVM enables seamless switching between multiple high-security networks using a single keyboard, monitor, and mouse.
With support for 4K UHD resolution (3840 x 2160 @ 30Hz), audio and USB, and secure isolated channel switching, it meets the demands of secure and high-performance workstations. The included CAC port ensures user authentication, and the optional extended warranty provides added peace of mind.
| Feature | Details |
|---|---|
| Manufacturer | Vertiv |
| Brand Name | Avocent |
| Product Series | Cybex SC900 |
| Model Number | SC945D-001 |
| Form Factor | Desktop |
| Video Interface | DisplayPort, HDMI |
| Max Video Resolution | 3840 x 2160 (4K UHD) @ 30Hz |
| No. of Computers Supported | 4 |
| No. of Users Supported | 1 Local |
| USB Ports | 11 |
| PS/2 Ports | 2 |
| DisplayPort Connections | 8 |
| HDMI Ports | 2 |
| Audio/USB Support | Yes |
| NIAP Compliance | PP 3.0 |
| TAA Compliant | Yes |
| Secure Channels | 3 Isolated |
| Height x Width x Depth | 2.2" x 13.7" x 5" |
| Weight | 3.70 lbs. |
| Shipping Weight | 6 lbs. |
| Warranty | 3-Year Limited (Full Coverage Factory Warranty) |
| Extended Warranty Option | Available |
| Country of Origin | United States |
