Description
The Vertiv Liebert GXT5-10KIRT5UXLN is a 10kVA/10kW online double-conversion UPS designed to protect mission-critical systems from power interruptions and disturbances. Featuring unity power factor (1.0), this 5U rack/tower convertible UPS ensures maximum usable power and efficiency. It comes with a built-in Vertiv RDU101 SNMP card for remote monitoring and a full-color LCD interface for intuitive local management. With zero transfer time, scalable runtime using external battery cabinets, and ENERGY STAR 2.0 certification, the GXT5 is ideal for IT networks, edge computing, healthcare, and financial institutions. This model includes a 5-year total warranty (3 years standard + 2 years extended).
| Category | Details |
|---|---|
| Brand | Vertiv Liebert |
| Series | GXT5 |
| Model | GXT5-10KIRT5UXLN |
| UPS Type | Online Double Conversion |
| Form Factor | Rack/Tower Convertible (5U) |
| Capacity | 10kVA / 10kW |
| Input Voltage | 230V AC (Range: 115V - 288V AC) |
| Output Voltage | 200/208/220/230/240V AC |
| Plug Type | Hardwired |
| Outlets | 4 x C13, 4 x C19 |
| Waveform | Pure Sine Wave |
| Transfer Time | 0 ns |
| Battery Type | Valve-Regulated Lead Acid (VRLA) |
| Battery Quantity | 16 |
| Battery Runtime | 2 min (Full Load), 7 min (Half Load) |
| Replaceable Battery | Yes |
| LCD Display | Full-Color Graphic, Gravity Sensing |
| Remote Management | RDU101 SNMP/Webcard |
| Bypass Options | Automatic & Manual |
| EPO (Emergency Power Off) | Yes |
| Operating Temperature | Up to 104°F (40°C) |
| Noise Level | 55 dB |
| Rack Height | 5U |
| Dimensions (HxWxD) | 8.5" x 16.9" x 24.8" |
| Weight | 164.24 lbs |
| Certifications | ENERGY STAR 2.0, RoHS, REACH, GS mark, IEC62040 standards |
| Included Accessories | UPS, SNMP card, USB cable, tower stands, rails, manuals |
| Warranty | 5-Year (3-Year Limited + 2-Year Extended) |
| Product Condition | New and Factory Fresh |
