Description
The SmartAVI MXWall-UHD 32x32 is a high-performance 4K video wall processor and matrix switch designed for mission-critical AV environments that demand seamless scalability, reliability, and visual precision. Supporting up to 32 HDMI inputs and 32 HDMI outputs, this all-in-one solution delivers ultra-high-definition content with integrated scaling and conversion, ensuring consistent image quality across complex video wall configurations.
Engineered for enterprise deployments, the MXWall-UHD enables flexible layout creation, real-time switching, and centralized control through multiple interfaces including TCP/IP, RS-232, and front panel controls. Its intuitive software interface allows users to design, manage, and modify video wall layouts with ease, offering unlimited customization for dynamic content display. With plug-and-play functionality and robust hardware architecture, it ensures rapid deployment and dependable long-term operation.
Ideal for control rooms, corporate environments, digital signage, retail, and command centers, the MXWall-UHD delivers exceptional performance with seamless switching, advanced scaling, and full UHD support for professional-grade visual systems.
| Specification | Details |
|---|---|
| Video Wall Capability | Supports flexible video wall layouts with unlimited configurations |
| Input Ports | 32 x HDMI |
| Output Ports | 32 x HDMI |
| Supported Resolutions | Up to 4K UHD (3840 x 2160 @ 60Hz), also supports 4K@30Hz and 1080p@60Hz |
| HDMI Standard | HDMI 2.0 compliant |
| HDCP Compliance | HDCP 2.2 |
| Video Bandwidth | 18 Gbps |
| Scaling | Integrated scaler converts any input resolution to UHD |
| Switching | Seamless switching with no signal interruption |
| Control Methods | TCP/IP (RJ-45), RS-232 (DB9), Front Panel Controls |
| Software | MXWall Manager software with drag-and-drop configuration |
| Audio Support | Stereo audio with 3.5mm input and output interfaces (32 channels each) |
| Configuration Modes | Video wall mode, individual display mode, custom layouts |
| Power Supply | 110–240 VAC, 50/60Hz |
| Power Consumption | 100W |
| Operating Temperature | 0°C to +40°C |
| Storage Humidity | 20% to 90% |
| Dimensions | 17” W x 7.125” H x 15” D |
| Weight | 24.45 lbs |
| Installation | Plug-and-play, no additional drivers required |
| Included Components | MXWall-UHD unit and power supply |
