Description
The SmartAVI MXWall-UHD-0412-S is a high-performance 4K60 video wall processor and matrix switch engineered for professional AV environments that demand precision, scalability, and reliability. Supporting 4 inputs and 12 outputs, this all-in-one solution enables seamless distribution and control of ultra-high-definition content across multi-display video walls.
Designed for enterprise-grade deployments, it features an integrated scaler and converter that ensures consistent 4K UHD output across all displays regardless of source resolution. With seamless switching, flexible layout configurations, and intuitive control options including TCP/IP, RS-232, and front panel access, the MXWall-UHD delivers operational efficiency for control rooms, command centers, digital signage networks, and corporate environments.
Its plug-and-play architecture reduces deployment complexity, while advanced software management allows users to create dynamic, customized video wall layouts with ease. Built for continuous operation, this system ensures dependable performance for mission-critical visual applications.
| Specification | Details |
|---|---|
| Video Wall Capability | Supports customizable layouts for multi-display video walls |
| Input Ports | 4 x HDMI (UHD 4K60 supported) |
| Output Ports | 12 x HDMI (UHD 4K60 supported) |
| Maximum Resolution | Up to 3840 x 2160 @ 60Hz |
| Video Bandwidth | Up to 18 Gbps |
| HDMI Standard | HDMI 2.0, HDCP 2.2 compliant |
| Scaling | Integrated scaler for resolution conversion to UHD |
| Switching | Seamless switching with no signal interruption |
| Control Methods | Front Panel, TCP/IP (LAN), RS-232 |
| Software Control | MXWall Manager (GUI-based configuration and layout control) |
| Display Modes | Video wall mode, individual display mode, custom layouts |
| Audio Support | Stereo audio with dedicated input and output interfaces |
| IR Control | IR input and output ports for remote operation |
| Network Interface | RJ-45 (TCP/IP control) |
| Power Supply | 110–240V AC, 50/60Hz |
| Power Consumption | Approx. 100W |
| Operating Temperature | 0°C to +40°C |
| Form Factor | Rackmount design |
| Application Use Cases | Control rooms, digital signage, retail displays, corporate AV, command centers |
