Description
The Kramer VP-427X1 is a high-performance 2x1 auto-switcher and scaler receiver designed for modern AV environments requiring seamless 4K signal handling, intelligent source selection, and long-reach HDBaseT connectivity. Engineered for reliability and flexibility, the VP-427X1 receives HDBaseT signals from compatible transmitters, converts them to HDMI, and scales video up or down to match any display resolution up to 4K@60Hz (4:4:4).
Featuring fast, clean source switching and Kramer’s advanced I-EDIDPro™ EDID management, the VP-427X1 ensures smooth presentations with plug-and-play simplicity. It automatically selects inputs based on priority or last-connected logic, with optional manual override. Audio de-embedding allows HDMI audio extraction to balanced analog outputs for streamlined integration with external sound systems.
Ideal for classrooms, conference rooms, corporate meeting spaces, and digital signage applications, this compact MegaTOOLS™ device supports PoE or 12V power, RS-232 and LAN control, CEC display automation, and wireless/wired switching with Kramer VIA. It delivers professional-grade performance with easy installation and dependable 4K signal extension up to 100m over standard copper cabling.
| Category | Details |
|---|---|
| Inputs | 1 HDBaseT (RJ-45), 1 HDMI (female) |
| Outputs | 1 HDMI (female), 1 Balanced Analog Stereo Audio (5-pin terminal block) |
| Ports | 1 IR In/Out (3.5mm), 1 RS-232 (3-pin terminal block), 1 Ethernet 100Mbps (RJ-45) |
| Supported Output Resolutions | Up to 4K@60Hz (4:4:4); multiple PC & HDTV formats including 640×480 to 2560×1600, 720p, 1080p, 2K, 4K |
| HDBaseT Range | 180m at 1080p@60; 100m at 4K@60 (4:2:0) |
| Latency | Up to 2 frames |
| Content Protection | HDCP 2.2/1.4 |
| Switching Time | <2.5 seconds |
| Control Options | Front-panel buttons, remote contact-closure, RS-232, Kramer API, embedded web UI via LAN |
| Indicators | Power, link, input selection LEDs |
| Power | PoE or 12V DC, 1.5A |
| Enclosure | MegaTOOLS® aluminum, convection-cooled |
| Environmental | Operating: 0°C to +40°C; Storage: –40°C to +70°C; Humidity: 10%–90% (non-condensing) |
| Included Accessories | Power adapter, rubber feet, mounting bracket |
| Product Dimensions | 18.75 × 14.50 × 2.54 cm (7.38" × 5.71" × 1.00") |
| Product Weight | 1.1 kg (2.4 lbs) approx. |
| Shipping Dimensions | 35.10 × 21.20 × 7.20 cm (13.82" × 8.35" × 2.83") |
| Shipping Weight | 1.8 kg (4.0 lbs) approx. |
