Description
The Kramer VS-44DT is a professional-grade 4x4 HDMI/HDBaseT matrix switcher designed for efficient signal distribution in advanced AV environments. Supporting 4K@60Hz (4:2:0) video, the unit routes any of its four HDMI inputs to any or all four HDBaseT outputs, with the first two outputs also providing simultaneous HDMI connectivity.
Engineered for extended-reach applications, the VS-44DT delivers video, audio, Ethernet, IR, and RS-232 over long distances while acting as a PoE provider for compatible HDBaseT receivers. With flexible control options—including an embedded web server and RS-232—the unit is ideal for conference rooms, auditoriums, command centers, and digital signage systems.
Additional features such as EDID capture, non-volatile memory, automatic output shutdown, and compatibility with leading HDBaseT receivers ensure reliable, high-performance operation in demanding AV installations.
| Category | Details |
|---|---|
| Inputs | 4 HDMI; 5 IR (3.5mm) |
| Outputs | 4 HDBaseT (RJ-45); 2 HDMI; 5 IR (3.5mm); 1 unbalanced stereo audio (3.5mm) |
| Ports | 1 Ethernet (RJ-45); 1 USB (program); RS-232 control (3-pin); RS-232 data (3-pin) |
| Max Data Rate | 10.2Gbps (3.4Gbps per graphic channel) |
| Supported Resolutions | VGA to WUXGA; 4K@30Hz Deep Color (up to 36bpp); 4K@60Hz (4:2:0) |
| HDMI Range | 15m @ 8-bit; 10m @ 12-bit |
| HDBaseT Range | 100m (4K@30Hz); 180m (1080p@60Hz@24bpp) |
| Power Consumption | 100–240V AC, 50/60Hz, 60VA |
| Operating Temp | 0°C to +40°C (32°F to 104°F) |
| Storage Temp | –40°C to +70°C (–40°F to 158°F) |
| Humidity | 10%–90% non-condensing |
| Cooling | Fan |
| Enclosure | Aluminum chassis |
| Regulatory Compliance | CE, RoHS, WEEE |
| Included Accessories | Rack ears, IR cables |
| Dimensions (W×D×H) | 19" × 13.90" × 1U (43.6cm × 35.3cm × 4.36cm) |
| Weight | 3.3kg (7.3lbs) |
| Shipping Dimensions | 54.30cm × 44.20cm × 10.70cm |
| Shipping Weight | 4.1kg (9.0lbs) |
