Description
The Edgecore SDW101-US SD-WAN Router delivers high-capacity, enterprise-grade networking designed to enhance performance, flexibility, and reliability across distributed sites. Built for large-scale enterprise applications, the SDW101 enables centralized management through the Edgecore SD-WAN Orchestrator—allowing IT teams to monitor, configure, and optimize branch networks in real time.
This x86 appliance-based solution features dual 10G WAN/LAN ports, eight Gigabit Ethernet interfaces, and intelligent traffic management with advanced QoS, VPN, and routing capabilities. It supports multi-tenant configurations, zero-touch provisioning, and automated over-the-air (OTA) firmware upgrades—reducing deployment time and operational complexity.
With adaptive WAN selection, policy-based routing, and stateful firewall protection, the SDW101-US ensures secure, high-performance connectivity optimized for cloud, VoIP, and mission-critical applications.
| Category | Details |
|---|---|
| Form Factor | 19” 1U Rack Mount (mounting bracket included) |
| Dimensions (W x D x H) | 44.2 × 29.8 × 4.4 cm |
| Weight | 3.1 kg (6.83 lbs) |
| Power Input | 100–240 VAC, 50/60 Hz |
| Operating Temperature | 0 °C – 40 °C (32 °F – 104 °F) |
| Operating Humidity | 20% – 90% non-condensing |
| WAN Interfaces | 2 × 10GBASE-T SFP+ |
| LAN Interfaces | 2 × 10GBASE-T SFP+, 8 × GE |
| Console Port | 1 × RJ-45 |
| USB Port | 1 × USB 3.0 |
| Throughput per Tunnel | Up to 320 Mbps |
| Tunnel Capability | Up to 1 Gbps |
| Concurrent Users | Up to 1,000 |
| Management | Central Management, Zero Touch Deployment, Auto Discovery & Provisioning, OTA Firmware Upgrade, TLS Encryption, Keep Alive Detection, NTP, Email Alerts, Event Logs, Disaster Recovery, Container Management |
| Routing | NAT, Static IP/DHCP/PPPoE, DHCP Server/Client, Static & Dynamic Routing (OSPF/BGP), Virtual Server / 1:1 NAT, Policy-based Routing |
| Security | Stateful Firewall, ACL by IP/Protocol/Application, Tunnel Isolation, TACACS+, URL Filter, DDoS Mitigation |
| VLAN Support | Configurable VLAN per port, DHCP Server per VLAN |
| QoS | Bandwidth & Priority Management, Session Control by IP/Protocol/Application |
| VPN | Split Tunnel, Complete Tunnel, Site-to-Site, Site-to-Client (WFH), Hub-Spoke / P2P Mesh |
| Adaptive WAN Selection | Multi-WAN, Auto Failover, Configurable Thresholds, Traffic Steering, Application Awareness, WAN Optimization |
| Package Analysis | Traffic Flow History, Top Applications & Sources by Volume |
| Monitoring | System Info, Traffic & Tunnel Statistics, WAN & VPN Quality, Container Status |
| Management Interfaces | SSH (v2), HTTP/HTTPS Web GUI, RESTful API |
| Platform Type | X86 Appliance-based / Cloud Platform |
| Typical Use Case | Large enterprise branches, multi-site deployments, cloud connectivity, and WAN optimization |
