Description
The Hanwha Vision WRR-P-E201W-16TB is a high-performance 1U Wisenet WAVE Recording Server purpose-built for enterprise-grade video surveillance. Pre-installed with Wisenet WAVE VMS and bundled with four Professional licenses, it enables rapid deployment and seamless integration with Wisenet and ONVIF-conformant IP cameras.
This Windows-based model delivers up to 470 Mbps recording throughput and supports up to 128 channels, making it ideal for large security environments. It comes equipped with 16TB raw storage (11TB usable after RAID 5 configuration) and features four 3.5" hot-swappable bays for continuous, optimized video recording.
Powered by an Intel Xeon E-Series processor and 16GB DDR4 RAM, the server includes dual 480GB SSDs in RAID 1 for fast OS performance and stability. The system supports RAID levels 0/1/5/6/10 with a 512MB NV cache, ensuring robust data protection and reliable uptime.
Designed for flexible installation and easy servicing, it comes with redundant 450W power supplies, IPMI remote management, HDMI/VGA outputs, USB 3.2 ports, and an included keyboard, mouse, and sliding rail kit with cable management.
This model is suited for mission-critical environments requiring dependable recording, resilient hardware architecture, and optimized performance.
| Category | Specification |
|---|---|
| SKU | WRR-P-E201W-16TB |
| Form Factor | 1U rackmount chassis |
| Operating System | Windows 11 IoT Enterprise LTSC 2024 |
| Video Management | Wisenet WAVE VMS (pre-installed) |
| Included Licenses | 4 × WAVE Professional Licenses |
| Recording Throughput | Up to 470 Mbps |
| Supported Channels | Up to 128 IP channels |
| Raw Storage | 16TB raw |
| Usable Storage (RAID 5) | Approximately 11TB |
| Data Drive Bays | 4 × 3.5" hot-swappable bays |
| OS Drives | 2 × 480GB SSD (RAID 1) |
| RAID Support | RAID 0 / 1 / 5 / 6 / 10 + 512MB NV cache |
| Processor | Intel Xeon E-Series (E2356G class) |
| Memory | 16GB DDR4 (2 × 8GB) |
| Network Interfaces | 2 × RJ45 1GbE (default) |
| Video Outputs | HDMI, VGA |
| USB Ports | 2 × USB 3.2 (front), 2 × USB 3.2 (rear) |
| Other Ports | Serial port |
| Remote Management | IPMI support |
| Power Supply | Dual redundant 450W, 80 Plus Platinum |
| Operating Temperature | 50°F – 95°F (10°C – 35°C) |
| Operating Humidity | 10% – 80% RH |
| Dimensions (W × D × H) | 17.3" × 19.6" × 1.7" (440 × 498 × 44 mm) |
| Weight | 50 lbs (chassis only, no HDDs) |
| Accessories Included | Keyboard, mouse, sliding rail kit with cable management arm |
| Certifications | BSMI, CE, FCC Class A, UL/cUL equivalent |
