Description
The Boxlight FrontRow IP Speaker Kit with CB75 Intercom Mic is a scalable network-based audio solution designed for school-wide paging, emergency alerts, bell schedules, announcements, and two-way intercom communication. Built for use with the FrontRow Conductor platform, this kit helps classrooms, hallways, gyms, auditoriums, and staff areas stay connected through reliable Ethernet-based communication.
This kit includes a flush-mount 1 x 2 ft lay-in ceiling speaker, plenum-rated ceiling enclosure, CB75 wall-mount intercom microphone with integrated speaker, CM900 networked audio controller, PoE extractor, and pre-wired components for faster deployment. It is ideal for rooms that need clear paging and intercom capability without requiring a full classroom audio amplification system.
Powered and networked through Ethernet, the system eliminates the need for AC wiring at the speaker location and supports centralized control for daily announcements, emergency messaging, and zone-based communication. For larger spaces, the system can support up to four total speakers with the required external power configuration.
| Specification | Details |
|---|---|
| Brand | Boxlight |
| Product Series | FrontRow |
| Product Type | IP speaker kit with intercom microphone |
| Compatible Platform | FrontRow Conductor |
| Primary Use | Paging, emergency alerts, bells, announcements, and two-way intercom communication |
| Recommended Environment | Classrooms, hallways, staff spaces, gyms, auditoriums, and school campus areas |
| Included Components | 1 x 2 ft lay-in ceiling speaker, ceiling enclosure, CB75 intercom microphone, cable locks, CM900 networked audio controller, and PoE extractor |
| Controller | CM900 networked audio controller |
| Controller Connectivity | RJ45 network, RJ45 LAN input, RJ45 intercom input, RJ45 CLAN power port, audio inputs, audio output, loudspeaker terminals, IR control, RS-232 serial control, relay output, page override detect, and alarm detect |
| Speaker Type | 8-inch full-range cone speaker in a 1 x 2 ft lay-in ceiling format |
| Speaker Sensitivity | 92 dBSPL at 1 W / 1 m |
| Speaker Impedance | 8 ohms nominal |
| Speaker Power Rating | 12 W RMS |
| Maximum System Output | 103 dBSPL at 12 W / 1 m |
| Frequency Response | 65 Hz to 17 kHz |
| Coverage Angle | 100 degrees included angle |
| Speaker Mounting | Replaces existing ceiling tile and mounts flush in standard ceiling grid |
| Speaker Dimensions | 11.81 x 12.81 x 3.81 in |
| Ceiling Enclosure | 1 x 2 ft plenum-rated ceiling enclosure |
| Enclosure Dimensions | 23.75 x 12 x 2.5 in |
| Enclosure Weight | 9 lb |
| Microphone | CB75 wall-mount intercom microphone with integrated speaker |
| Microphone Installation | Fits standard North American single-gang electrical boxes |
| Microphone Connection | RJ45 jack using Cat 5 cable or better |
| Microphone Power | +12 V, 100 mA over UTP Cat 5e from compatible controller |
| PoE Support | IEEE 802.3at PoE extractor |
| PoE Network Support | 10/100/1000 Mb/s |
| PoE Power Output | 12 VDC at 1.75 A |
| PoE Protection | Over-current, over-temperature, over-voltage, and short-circuit protection |
| Power Requirement | PoE powered, with no AC wiring required at the speaker location |
| Expandability | Supports up to four total speakers per location when configured with required external power |
| Installation Features | Flush ceiling-grid mounting, pre-wired assembly, cable locks, and network-based setup |
| Key Benefits | Centralized paging, emergency alerts, bell schedules, classroom intercom, and scalable campus communication |
