Description
Ensure uninterrupted power with the Vertiv Geist rPDU VA4N3201, a 20-outlet rack-mounted auto transfer switch (ATS) power distribution unit designed to protect single-corded devices. Featuring dual NEMA L5-30P inputs and 20 x NEMA 5-20R outputs, this monitored PDU rapidly transfers load within 4–8 milliseconds during power failure—no phase synchronization needed.
With built-in overcurrent protection, network monitoring (RJ-45), and support for environmental sensors, it’s ideal for high-availability environments. Daisy-chain up to 50 units using a single IP address with fault-tolerant RSTP. Includes LCD display, horizontal rack-mount design, and a 10-foot cord.
| Specification | Details |
|---|---|
| Manufacturer | Vertiv |
| Brand Name | Geist |
| Series | rPDU |
| Model | AN03E2R1-20S203-3TL5TL5A011-D |
| Part Number | VA4N3201 |
| Product Type | Monitored Auto Transfer Switch PDU |
| Plug Type | 2 x NEMA L5-30P |
| Outlet Type | 20 x NEMA 5-20R |
| Load Capacity | 2800 W |
| Input Voltage Range | 100–120V AC |
| Output Voltage | 120V AC |
| Input Frequency | 60 Hz |
| Input Current | 30 A |
| Circuit Breaker | Yes |
| Protection | Overcurrent, Single Pole |
| Network Interface | RJ-45 |
| Network Protocols | SNMP, DHCP, HTTPS, SSH, JSON, Modbus TCP, etc. |
| Mounting Type | Rack-mountable |
| Mount Orientation | Horizontal |
| Cord Length | 10 ft |
| Dimensions (H x W x D) | 3.4" x 17" x 18" |
| Color | Black Powder Coat |
| Max Operating Temp. | 140°F (60°C) |
| Certifications | UL, c-UL 62368-1, FCC Part 15 Class A |
| Compliance | RoHS |
| Warranty | 5 years (with registration), 3 years standard |
| Shipping Weight | 12 lbs. |
