Description
The AudioCodes MP1288-144S-2AC-TAA is a high-density analog VoIP gateway engineered for large-scale enterprise, hospitality, government, and campus deployments that require reliable integration of legacy analog devices into modern IP telephony networks. Supporting 144 FXS ports, this gateway enables organizations to extend the life of existing analog phones, fax machines, elevator lines, and modems while transitioning to all-IP environments.
Designed with TAA compliance, dual redundant AC power supplies, and front-to-rear cooling, the MP1288 delivers exceptional resiliency and operational stability. Advanced telephony capabilities—including SRTP on all channels, G.168 echo cancellation, T.38v3 fax support, SIP header manipulation, and survivability features—ensure secure, high-quality communication across all analog endpoints.
With its 3U rack-mount form factor, integrated surge protection, and interoperability with leading SIP platforms, the MP1288-144S-2AC-TAA provides a scalable, future-ready solution for organizations upgrading to IP communications without sacrificing their existing infrastructure.
| Category | Specification |
|---|---|
| Brand | AudioCodes |
| Model / SKU | MP1288-144S-2AC-TAA |
| Product Type | High-Density Analog VoIP Gateway |
| TAA Compliant | Yes |
| FXS Capacity | 144 FXS ports (supports short and long haul up to 7.5 km) |
| FXO Ports | 0 |
| Ethernet Ports | 2 × 10/100/1000Base-T (RJ-45) with 1+1 redundancy |
| Connection Type | RJ-45; Amphenol cable required (not included) |
| Surge Protection | Integrated surge protection per ITU-T K.21 (FXS ports) |
| Voice Processing | G.168 echo cancellation, jitter buffer, packet loss concealment, silence suppression |
| Voice Codecs | G.711, G.723.1, G.726, G.729A/B, G.722, AMR-NB, Opus-NB |
| Fax Support | T.38, T.38v3, bypass |
| Security | SRTP on all channels |
| Protocols Supported | SIP (UDP/TCP/TLS) |
| SIP Header Manipulation | Yes |
| 3-Way Conferencing | Up to 24 three-way conferences across FXS blades |
| Call Routing | Least-cost routing, ENUM, LDAP, call forking, load balancing |
| Management Interfaces | Web GUI, SSH/Telnet, SNMP v2/v3, REST API |
| Mounting | 3U rackmount, 19-inch |
| Power Supply | Dual redundant AC 100–240V |
| Power Consumption (144 ports) | 350 W (short haul), 600 W (long haul) |
| Dimensions (W × H × D) | 438 × 131.2 × 451 mm |
| Weight | 21 kg (fully populated) |
| Operating Temperature | 0°C to 40°C |
| Humidity | 5%–90% non-condensing |
| Cooling | Front-to-rear airflow |
| Additional Features | Survivability, emergency phone support, SBC capabilities, message waiting indication |
