Description
The Promise VTrak E5800F is an enterprise-class SAN storage system designed for high-performance and high-availability environments. With 288TB installed capacity across 24 x 12TB drives, dual 12Gb/s SAS controllers, and four 16Gb Fibre Channel ports, the E5800F delivers industry-leading throughput and IOPS. Ideal for demanding data center, virtualization, and surveillance applications, it supports advanced RAID levels, VMware environments, and scalable deployments. Housed in a 4U rack-mount form factor with redundant components, the E5800F ensures continuous operation and efficient power usage for enterprise workloads.
| Category | Details |
|---|---|
| Manufacturer | Promise Technology |
| Part Number | E5800FDQS12 |
| Product Line | VTrak |
| Series | E5000 |
| Model | E5800F |
| Form Factor | Rack-mountable (4U) |
| Installed Storage | 288TB (24 x 12TB HDD) |
| Drive Bays | 24 x 3.5ā Bays |
| Drive Interface | 12Gb/s SAS |
| Controllers | Dual Controller (2 x 12Gb/s SAS) |
| RAID Levels Supported | 0, 1, 5, 6, 10, 50, 60 |
| Host Interface | 4 x 16Gb Fibre Channel |
| Expansion Interface | 12Gb/s SAS |
| Network Interface | Gigabit Ethernet, RJ-45 |
| Protocols Supported | Telnet, LDAP, SSH, SNMP, CIM, FCP |
| Virtualization Compatibility | VMware vSphere, Citrix XenServer, Microsoft Hyper-V |
| Dimensions (HxWxD) | 6.9" x 17.6" x 20" |
| Weight | Approx. 109.35 lbs (Shipping: 113 lbs) |
| Environmental Compliance | RoHS, WEEE |
| Warranty | 3-Year Limited Warranty with Optional Onsite Parts Replacement |
