Description
The HPE 1x1x8 G4 KVM IP Console Switch (Q1P54A) delivers secure, remote, and centralized management for up to 8 connected servers and IT devices. Designed for IT professionals operating in high-demand server environments, this advanced KVM switch supports both local and remote access with virtual media capabilities, enabling secure device management from anywhere.
This enterprise-grade solution improves IT asset utilization and simplifies deployments with tiering support for up to 256 servers. Integrated remote management features include browser-based access via OBWI, programmable scanning, and seamless switching between KVM and iLO sessions. Multiple mounting options—0U rear or side—offer space-saving flexibility in data center racks. Pair with an HPE LCD8500 for optimal local operation.
| Specification | Details |
|---|---|
| Model | Q1P54A |
| Form Factor | 1U rackmount / 0U rear or side-mount capable |
| Input Voltage | 100–240 VAC auto-sensing (50–60 Hz) |
| Input Power | 100W max |
| Heat Output | 340 BTU/hr max |
| Server Ports | 8 |
| Max Server Connections | Up to 256 (via tiering) |
| Users Supported | 2 (1 local + 1 remote) |
| Tiering Support | Yes (two levels, virtual media compatible) |
| Virtual Media | Local and remote media mapping supported |
| Management Interface | On-Board Web Interface (OBWI), Local OSD |
| Mounting Options | Front/rear 1U, 0U side-mount (HPE racks only) |
| Cable Included | 1x CAT5 power jumper cable |
| Dimensions (HxWxD) | 1.72 x 17.0 x 6.69 in |
| Weight | 4.4 lb |
| Warranty | 3-Year limited warranty |
