Description
The HPE Aruba Networking AP-677 (JPF1) is a high-performance tri-radio outdoor access point delivering blazing-fast Wi‑Fi 6E connectivity in environmentally challenging locations. Part of the 670 Series, this TAA-compliant model supports the 2.4 GHz, 5 GHz, and 6 GHz bands with built-in directional antennas, ideal for high-density outdoor environments and IoT deployments.
With a maximum aggregate data rate of 3.9 Gbps, 2.5 GbE and SFP wired uplinks, integrated GPS, and robust weatherproofing, the AP-677 is optimized for enterprises, industrial facilities, and smart cities. It also features high-power Bluetooth and Zigbee radios for seamless IoT integration, advanced security with Dynamic Segmentation and WPA3, and operates as a Standard Power (SP) Wi‑Fi 6E device.
| Specification | Details |
|---|---|
| Product Number | S0Q42A |
| Model Name | AP‑677 (JPF1) |
| AP Type | Outdoor tri-radio (2.4GHz, 5GHz, 6GHz) Wi‑Fi 6E |
| Max Aggregate Throughput | Up to 3.9 Gbps |
| MIMO Configuration | 2x2:2 on all three bands |
| Wi‑Fi Standard | IEEE 802.11ax (Wi‑Fi 6E) |
| Antenna Type | Internal directional antennas |
| Antenna Gain | 2.4 GHz: 6.9 dBi 5 GHz: 6.5 dBi 6 GHz: 6.9 dBi |
| IoT Radios | Integrated Bluetooth and Zigbee (4.5 dBi peak gain) |
| Client Capacity | Up to 512 clients per radio |
| BSSIDs per Radio | Up to 16 (8 on 6 GHz) |
| Ports | 1x 2.5 GbE RJ-45, 1x 1 GbE SFP fiber port |
| Power Input | IEEE 802.3bt PoE or direct DC (via optional power supply) |
| Power Consumption | Max 45.5W |
| Mounting | Pre-installed bracket (mount kits sold separately) |
| Location Awareness | Embedded GPS |
| Security Features | WPA3, Enhanced Open, TPM, Dynamic Segmentation, Policy Enforcement Firewall |
| Certifications | Wi‑Fi Alliance, Bluetooth SIG, Ethernet Alliance, TAA-compliant |
| Environmental Durability | Temperature hardened, weatherproof, ruggedized for hazardous locations |
| Warranty | Limited lifetime warranty |
