Description
The ASUS PE3000G-I7M7-3202 is a rugged, fanless industrial edge AI computer engineered for reliability in demanding environments. Powered by a 12th Gen Intel® Core™ i7-12800HE processor and expandable up to 64 GB DDR5 SDRAM, it delivers exceptional computing power for edge analytics, automation, and intelligent vision applications.
With support for NVIDIA® Ampere/Turing™ or Intel® Arc™ A-series MXM GPUs, the PE3000G offers advanced AI acceleration and 4K multi-display output. It features four LAN ports (including three 2.5 GbE with optional PoE+) and wide DC input (8–48 V) for flexible deployment.
Certified to MIL-STD-810H, CE/FCC, and BSMI standards, this compact system operates reliably in extreme conditions from –20 °C to 60 °C. Designed with a patented thermal solution, multiple M.2 expansion options, and robust power control, the PE3000G-I7M7-3202 redefines performance and durability for modern industrial edge computing.
| Category | Specification |
|---|---|
| Processor | Intel® Core™ i7-12800HE (14 cores, 20 threads, 2.4 GHz base / 4.6 GHz turbo, 45 W TDP) |
| Chipset | Intel C621A (integrated platform controller) |
| Graphics | Integrated Intel® Iris® Xe Graphics (i7/i5 SKUs); optional MXM GPU support (NVIDIA® Ampere/Turing™ or Intel® Arc™ A-series) |
| Memory | 2× SO-DIMM DDR5 4800 MHz (up to 64 GB) |
| Storage | 2× hot-swappable 2.5" SATA HDD/SSD ( RAID 0/1 support ) • 1× M.2 2280 M-key PCIe Gen 4 ×4 NVMe |
| Expansion Slots | 1× Mini PCIe (full size, cellular module) • 1× M.2 2230 E-key (Wi-Fi 5/6) • 1× M.2 3042/3052 B-key (4G/5G NR with SIM slot) • MXM PCIe x8 Gen4 |
| Ethernet | 1× Intel® I219-LM (1 GbE) • 3× Intel® I226-IT (2.5 GbE) • Optional IEEE 802.3at PoE+ PSE (100 W total budget) |
| USB Ports | 3× USB 3.2 Gen 2 Type-A (10 Gbps, screw-lock) • 1× USB 2.0 Type-A |
| Display Outputs | 2× HDMI 1.4 (up to 4096 × 2304 @ 30 Hz) • 2× DP++ (up to 4096 × 2304 @ 60 Hz) • 4× DP (via optional MXM GPU) |
| Serial Ports | 2× RS-232/422/485 (DB9) • 2× RS-232 (DB9, optional) • Optional CAN Bus support |
| Digital I/O | 4× DI, 4× DO (optional, isolated terminal block) |
| Audio | Mic-in / Line-out |
| Power Input | 8 – 48 V DC input (3-pin terminal block) • Built-in ignition power control • Optional 330 W / 480 W adapter |
| Mounting Options | Desktop mount / Wall mount |
| Dimensions (W×D×H) | 240 × 230 × 125.7 mm |
| Weight | 8.2 kg |
| Operating Temperature | –20 °C to 60 °C (with 45 W CPU and 60 W MXM GPU) |
| Storage Temperature | –40 °C to 85 °C |
| Relative Humidity | 10 – 95% (non-condensing) |
| Durability | MIL-STD-810H vibration (5 Grms, 5–500 Hz, 3 axes); shock 20 G |
| Certifications | CE/FCC Class A/B, BSMI, CB, CE-LVD, RoHS |
| OS Support | Windows 11 IoT Enterprise (64-bit), Windows 10 IoT Enterprise (64-bit), Linux (Project based support) |
